43 inch infrared touch screen

Features:

  High sensitivity, fast speed, no drift phenomenon;

  Industrial integration main board, Complete features, more stable performance;

  High-performance LCD screen to ensure high clarity, high brightness and high stability of the images;

  Adopt high quality capacitor touch panel, ultra-high light permeability, strong anti- riot, scratch resistance, dust-proof and waterproof;

  Support LVDS/VGA/HDMI asynchronous dual display;

  The shell adopts high-strength hardware design, the appearance is extremely thin, beautiful and strong, have excellent protection level and electromagnetic shielding performance;

  Paint of surface, smooth and uniform, simple and generous, color and industrial host integrated;

  High reliability, high stability, applicable to education and training, exhibition, public media, video conferencing, military command, traffic management;

  The base color and shape can be customized.


Parameter

  Model  LD-PC4301A
  Screen parameter
  Size  43Inch
  Display area  941.184*529.416mm/16:9
  Pixel Pitch  0.4902*0.4902
  Resolution  1920*1080
  Brightness  300cd/㎡
  Contrast  1200:1
  Viewing angel  178°
  Life time  ≥60000 Hours
  Touch screen parameter
  Touch Specifications  Infrared touch
  Touch Mode  Non-contact touch
  Resolution  4096*4096
  Respond time  ≤8ms
  Positioning precision  ≥Ø5mm
  Transmittance  ≥95%
  Move  Fall, lift, hold (right-click)
  Life time  ≥60000 Hours
  Built-in computer configuration
  CPU  I5 (I3/I5/I7 optional)
  Memory card  4G(8/16G optional)
  Solid state disc(SSD)  120G(240/256G SSD optional)
  Output interface  VGA、HDMI、USB2.0*4、RJ45&RJ11、Audio I/O Interface、
  RS232(optional)
  3G/4G/WIFI  Optional
  Power supply
  Input voltage  AC 110V-240V 50/60Hz
  Power  ≤120W
  Appearance
  Material  Steel Structure cold common (SPCC) or Customized
  Color  Silver gray or Customized
  Installation  Wall mount、Floor mount、Base mount
  Dimension  1016.5*604*89mm (contain wall hanging)
  Working environment
  Working temperature  0-60℃
  Working humidity  80%RH
  Avoid direct sunlight; Ensure working voltage stability.
  Accessories  Power cord, certificate of conformity, warranty card, manual.
